Resetting the system

The last break time is set to 00:00 and the driver's attention level is set to 5 (very attentive) when the driver resets the Driver Attention Warning system.
The driver attention warning system resets in the following situations.
- The engine is turned OFF.
- The driver unfastens the seat belt and then opens the driver’s door.
- The driver takes a break from driving that lasts more than 10 minutes.
The driver attention warning system operates again, when the driver restarts driving.

System disabled

The Driver Attention Warning system enters the ready status and displays the 'Disabled' screen in the following situations.

- The camera sensor is unable to detect the lanes.
- Driving speed remains under 60 km/h (37 mph) or over 180 km/h (112 mph).

System setting and activation

System setting The Driver Attention Warning system is set in the OFF position when your vehicle is first delivered to you from the factory. To turn ON the Driver Attention Warning system, tur ...

System malfunction

When the “Check System” warning message appears, the system is not working properly. In this case, have the vehicle inspected by an authorized Kia dealer. WARNING The Driver Attention War ...
