Kia Stinger (CK) 2018-2023 Owner's Manual: Variable Charge Motion Actuator (VCMA)
Components and components location Components ECM directly controls the actuator and the rotation of motor operates the VCM flap of intake manifold in link structure to create tumble in air. Mounted inside the actuator, the motor and position sensor sense the position of flap and send feedback to ECM to determine the current location of flap and detect abnormal operation due to adherence of foreign substance.Repair procedures Removal 1. Turn ignition switch OFF and disconnect the negative (-) battery cable. 2. Remove the luggage side trim. (Refer to Body - "Luggage side trim") 3. Disconnect the ECS control unit connector (A). 4. Loosen the ECS control unit bracket nut and then remove the ECS control unit (A).
