Kia Stinger CK: Driveshaft and axle / Specifications

Kia Stinger (CK) 2018-2023 Service Manual / Driveshaft and axle / Specifications

Service data
Service Data

Items
Inner side
Outer side
Front driveshaft
Joint type
HUJ#26
WTJ#24
Max. permissible angle
28°
54°
Rear driveshaft
Joint type
CGJ#26
CGJ#26
Max. permissible angle
20°
20°

Front differential
Oil type
Hypoid gear oil MS517-15 GT 75W/85 (GL-5)
(SK HK SYN GEAR OIL 75W/85  Equivalent)
Oil capacity(ℓ)
0.7 ± 0.05
Reduction gear type
Hypoid gear
Reduction gear ratio
THETA II 2.0 T-GDI : 3.727
R 2.2 : 3.385
LAMBDA II 3.3 T-GDI : 3.538
Differential gear backlash (mm)
0.05 - 0.12

Rear differential
Oil type
Hypoid gear oil MS517-15 GT 75W/85 (GL-5)
(SK HK SYN GEAR OIL 75W/85  Equivalent)
LSD Oil type
Hypoid gear oil MS517-15 GTL 75W/85 (GL-5)
(SK HK SYN LSD GEAR OIL 75W/85  Equivalent)
Oil capacity(ℓ)
THETA II 2.0 T-GDI & R 2.2 : 1.15 - 1.25
LAMBDA II 3.3 T-GDI : 1.25 - 1.35
LSD Oil capacity(ℓ)
THETA II 2.0 T-GDI & R 2.2 : 1.25 - 1.35
LAMBDA II 3.3 T-GDI : 1.35 - 145
Reduction gear type
Hypoid gear
Reduction gear ratio
THETA II 2.0 T-GDI : 3.727
R 2.2 : 3.385
LAMBDA II 3.3 T-GDI : 3.538
Differential gear backlash (mm)
0.07 - 0.15

Tightening torque
Tightening Torques

Item
Tightening torque
N·m
kgf·m
lb·ft
Front
Wheel nut
107.9 - 127.5
11.0 - 13.0
79.6 - 94.0
Drive shaft caulking nut
196.1 - 255.0
30.0 - 32.0
144.7 - 188.1
Wheel speed sensor mounting bolt
6.9 - 10.8
0.7 - 1.1
5.1 - 8.0
Hub assembly mounting bolt
88.3 - 107.9
9.0 - 11.0
65.1 - 79.6
Lateral arm ball joint mounting bolt
88.3 - 107.9
9.0 - 11.0
65.1 - 79.6
Compression arm ball joint mounting bolt
88.3 - 107.9
9.0 - 11.0
65.1 - 79.6
Tie rod end ball joint mounting nut
88.3 - 107.9
9.0 - 11.0
65.1 - 79.6
Rear
Wheel nut
107.9 - 127.5
11.0 - 13.0
79.6 - 94.0
Drive shaft caulking nut
294.2 - 313.8
30.0 - 32.0
217.0 - 231.5
Shock absorber lower mounting bolt & nut
156.9 - 176.5
16.0 - 18.0
115.7 - 130.2
Brake disc mounting screw
4.9 - 5.9
0.5 - 0.6
3.6 - 4.3
Wheel speed sensor mounting bolt
6.9 - 10.8
0.7 - 1.1
5.1 - 8.0
Hub assembly mounting bolt
88.3 - 107.9
9.0 - 11.0
65.1 - 79.6
Upper arm front mounting bolt&nut
117.7 - 132.4
12.0 - 13.5
86.8 - 97.6
Upper arm rear mounting bolt&nut
117.7 - 132.4
12.0 - 13.5
86.8 - 97.6
Lower arm mounting bolt&nut
156.9 - 176.5
16.0 - 18.0
115.7 - 130.2
Assist arm mounting bolt
156.9 - 176.5
16.0 - 18.0
115.7 - 130.2
Trailing arm mounting nut
117.7 - 132.4
12.0 - 13.5
86.8 - 97.6
Propeller shaft
Front propeller shaft mounting bolt
88.3 - 107.9
9.0 - 11.0
65.1 - 79.6
Propeller shaft center bearing bracket mounting bolt
49.0 - 63.7
5.0 - 6.5
36.1 - 47.0
Rear propeller shaft mounting bolt
88.3 - 107.9
9.0 - 11.0
65.1 - 79.6
Rear differential
Rear differential cover bolt
39.2 - 49.0
4.0 - 5.0
28.9 - 36.1
Rear differential mounting bolt
68.6 - 88.3
7.0 - 9.0
50.6 - 79.6
Front differential
Front differential cover mounting bolts
58.8 - 63.7
6.0 - 6.5
43.4 - 47.0

Lubricant
Lubricants

Item
Lubricants
Quantity
Front Drive Shaft
Inner (RH,LH)
CW-13TJ
180 - 190g
Outer (RH,LH)
RBA
155 - 165g
