Kia Stinger: Body (Interior and Exterior) / Specifications
Kia Stinger CK 2018-2024 Service Manual / Body (Interior and Exterior) / Specifications
Service data
| Service Data |
|
Items |
Specification |
|
|
Hood |
Type |
Rear hinged, gas lifter type |
|
Front Door |
Structure |
Front hinged, full door structure |
|
Regulator system |
Wire drum type |
|
|
Locking system |
Pin-fork system |
|
|
Rear Door |
Structure |
Front hinged, full door structure |
|
Regulator system |
Wire drum type |
|
|
Locking system |
Pin-fork system |
|
|
Trunk Lid |
Type |
Front hinged, power trunk lid type (option ) |
|
Seat Belts |
Front |
3-point type with Emergency Locking Retractor (E.L.R.) |
|
Rear |
3-point type with Emergency Locking Retractor (E.L.R.) |
|
Tightening torque
| Tightening Torque |
|
Items |
N·m |
Kgf·m |
lb·ft |
|
|
Front and rear doors |
Door hinge to body |
37.3 - 41.2 |
3.8 - 4.2 |
27.5 - 30.4 |
|
Door hinge to door |
21.6 - 26.5 |
2.2 - 2.7 |
15.9 - 19.5 |
|
|
Door checker to door |
6.9 - 10.8 |
0.7 - 1.1 |
5.1 - 8.0 |
|
|
Door checker to body |
19.6 - 29.4 |
2.0 - 3.0 |
14.5 - 21.7 |
|
|
Outside handle base mounting bolt |
5.9 - 7.8 |
0.6 - 0.8 |
4.3 - 5.8 |
|
|
Door latch mounting bolts |
6.9 - 10.8 |
0.7 - 1.1 |
5.1 - 8.0 |
|
|
Door module mounting bolts |
7.8 - 11.8 |
0.8 - 1.2 |
5.8 - 8.7 |
|
|
Door glass mounting bolt |
7.8 - 11.8 |
0.8 - 1.2 |
5.8 - 8.7 |
|
|
Door striker mounting bolts |
18.7 - 21.6 |
1.7 - 2.2 |
12.3 - 15.9 |
|
|
Trunk Lid |
Trunk lid striker mounting bolts |
21.6 - 26.5 |
2.2 - 2.7 |
15.9 - 19.5 |
|
Trunk lid latch mounting bolts |
6.9 - 10.8 |
0.7 - 1.1 |
5.1 - 8.0 |
|
|
Trunk lid key holder mounting bolts |
6.9 - 10.8 |
0.7 - 1.1 |
5.1 - 8.0 |
|
|
Trunk lid hinge to trunk lid |
6.9 - 8.8 |
0.7 - 0.9 |
5.1 - 6.5 |
|
|
Hood |
Hood hinge to body |
21.6 - 26.5 |
2.2 - 2.7 |
15.9 - 19.5 |
|
Hood hinge to hood |
21.6 - 26.5 |
2.2 - 2.7 |
15.9 - 19.5 |
|
|
Hood latch to body |
7.8 - 11.8 |
0.8 - 1.2 |
5.8 - 8.7 |
|
|
Seat |
Front seat mounting bolts |
49.0 - 63.7 |
5.0 - 6.5 |
36.2 - 47.0 |
|
Rear seat back mounting bolts |
16.7 - 25.5 |
1.7 - 2.6 |
12.3 - 18.8 |
|
|
Rear seat frame mounting bolts |
16.7 - 25.5 |
1.7 - 2.6 |
12.3 - 18.8 |
|
|
Rear seat frame mounting nuts |
16.7 - 25.5 |
1.7 - 2.6 |
12.3 - 18.8 |
|
|
Seat belt |
Height adjuster mounting bolts |
39.2 - 53.9 |
4.0 - 5.5 |
28.9 - 39.8 |
|
Front seat belt upper anchor mounting bolt |
39.2 - 53.9 |
4.0 - 5.5 |
28.9 - 39.8 |
|
|
Front seat belt lower anchor mounting bolt |
39.2 - 53.9 |
4.0 - 5.5 |
28.9 - 39.8 |
|
|
Front seat belt pretensioner upper mounting bolt |
39.2 - 53.9 |
4.0 - 5.5 |
28.9 - 39.8 |
|
|
Front seat belt pretensioner lower mounting bolt |
7.8 - 11.8 |
0.8 - 1.2 |
5.8 - 8.7 |
|
|
Rear seat belt lower anchor mounting bolts |
39.2 - 53.9 |
4.0 - 5.5 |
28.9 - 39.8 |
|
|
Rear center seat belt retractor mounting bolt |
39.2 - 53.9 |
4.0 - 5.5 |
28.9 - 39.8 |
|
|
Rear seat belt retractor mounting bolt |
39.2 - 53.9 |
4.0 - 5.5 |
28.9 - 39.8 |
|
|
Seat belt buckle mounting bolt |
39.2 - 53.9 |
4.0 - 5.5 |
28.9 - 39.8 |
|
|
Outside rearview mirror |
Outside rearview mirror mounting nuts |
6.9 - 10.8 |
0.7 - 1.1 |
5.1 - 8.0 |
|
Wiper arm |
Wiper arm mounting nuts |
22.6 - 31.4 |
2.3 - 2.7 |
16.6 - 19.5 |
|
Quarter fixed glass |
Quarter fixed glass mounting nuts |
3.9 - 4.4 |
0.4 - 0.45 |
2.9 - 3.3 |
|
Panorama sunroof |
Panorama sunroof mounting nuts |
7.8 - 11.8 |
0.8 - 1.2 |
5.8 - 8.7 |
|
Panorama sunroof mounting bolts |
7.8 - 11.8 |
0.8 - 1.2 |
5.8 - 8.7 |
|
Body (Interior and Exterior)
Special service tools
Special Service Tools
Tool (Number and name)
Illustration
Use
09880-4F000
Hog ring clip installer
...
