Oil pressure characteristics input

Oil-pressure characteristics input

Solenoid valve oil-pressure characteristics input procedure

1.	Perform the oil-pressure characteristics input procedure using the KDS.

2.	Click the "OK" button after checking the condition.

3.	Click the "OK" button after selecting the replaced solenoid valve.

4.	Check the code that was recorded before installing the new solenoid valve.

5.	Click the "OK" button after inputting oil pressure characteristics for the replaced solenoid valve.
