Kia Stinger: Steering System / Specifications
Kia Stinger CK 2018-2024 Service Manual / Steering System / Specifications
Service data
| Specifications |
|
Item |
Specification |
|
|
Type |
Motor Driven Power Steering |
|
|
Steering gear |
Type |
Rack & Pinion |
|
Rack stroke |
2WD : 152.0 ± 1 mm (5.9842 ± 0.0393 in.) AWD : 146.0 ± 1 mm (5.7480 ± 0.0393 in.) |
|
|
Steering angle (Max.) |
Inner |
2WD : 39.65° AWD : 37.69° |
|
Outer |
2WD : 33.19° AWD : 31.92° |
|
Tightening torque
| Tightening Torques |
|
Item |
Tightening torque (kgf·m) |
||
|
N·m |
kgf·m |
lb·ft |
|
|
Hub nuts |
107.9 - 127.5 |
11.0 - 13.0 |
79.6 - 94.0 |
|
Steering wheel lock bolt |
44.1 - 49.0 |
4.5 - 5.0 |
32.5 - 36.2 |
|
Steering column mounting nut |
24.5 - 29.4 |
2.5 - 3.0 |
18.1 - 21.7 |
|
Steering column mounting bolt |
53.9 - 58.8 |
5.5 - 6.0 |
39.8 - 43.4 |
|
Universal joint to pinion of steering gear |
32.4 - 37.3 |
3.3 - 3.8 |
23.9 - 27.5 |
|
Tie rod end castle nut |
107.9 - 127.5 |
11.0 - 13.0 |
79.6 - 94.0 |
|
Steering gear box mounting bolts |
107.9 - 127.5 |
11.0 - 13.0 |
79.6 - 94.0 |
Steering System
Repair procedures
Service Adjustment Procedure
Steering Wheel Play
Inspection
1.
Turn the steering wheel so that the front wheels are facing straight
ahead.
...
Steering wheel
Components and components location
Components
1. Steering wheel body
2. Remote control switch
3. Paddle shift
4. Lower cover
5. Wiring
6. Damper
...
