Kia Stinger (CK) 2018-2023 Owner's Manual: Console Temperature Control Actuator

Repair procedures Inspection 1. Turn the ignition switch OFF. 2. Disconnect the mode control actuator connector. 3. Verify that the mode control actuator operates to the defrost mode when 12V is connected to terminal 3 and ground to terminal 7. Verify that the mode control actuator operates to the vent mode when connected in reverse.

Kia Stinger (CK) 2018-2023 Owner's Manual: Rear Console Cover

Components and components location Component Location 1. Rear console cover Repair procedures Replacement    Put on gloves to protect your hands.    • Use a plastic panel removal tool to remove interior trim pieces without marring the surface.
