Kia Stinger (CK) 2018-2023 Service Manual: Brake switch
Components and components location
Components
1. Brake switch
2. Brake pedal
Schematic diagrams
Terminal function
Pin No
Description
1
IGN1
2
IBU
3
-
4
B+
5
Stop lmap
6
Ground
Troubleshooting
Troubleshooting
1.
Kia Stinger (CK) 2018-2023 Service Manual: Seat Belt Buckle Switch (BS)
Description and operation
Description
The SRSCM shall monitor the status of the driver and front passenger seat belt
buckle. The SRSCM provides one pin each for the driver and front passenger seat
belt buckle status input. The seat belt buckle circuit operates from internal boost
voltage supplied by the SRSCM, and uses chassis ground for the signal return.
