Kia Stinger CK: ISG (Idle Stop & Go) System / Brake Booster Vacuum Pressure Sensor

Description and operation
Description

In order to ensure adequate brake power assistance in every situation, the brake booster is equipped with a partial vacuum sensor. The brake booster vacuum pressure sensor is located beside the brake booster.

Schematic diagrams
Circuit Diagram

Repair procedures
Inspection
1.

Check for loose connection of BBCPS and vacuum hose, and damage of vacuum hose.

2.

Connect KDS to DLC (Data Link Cable).

3.

Warm up the engine to normal operating temperature.

4.

Monitor "BBVPS" parameter on KDS.

Other information:

Kia Stinger (CK) 2018-2023 Service Manual: Crash Pad

Components and components location Components 1. Cowl cross member bar 2. Main wiring 3. Main crash pad 4. Side air vent duct [RH] 5. Crash pad under cover [RH] 6. Crash pad lower panel [RH] 7. Crash pad center lower cover 8. Glove box housing 9. Fuse A/S cover 10. Crash pad garnish [RH] 11.

Kia Stinger (CK) 2018-2023 Service Manual: Heater Core

Repair procedures Replacement 1. Disconnect the negative (-) battery terminal. 2. After loosening the nuts and bolts, remove the main crash pad and cowl cross bar assembly altogether. (Refer to Heater - "Heater Unit") 3. Remove the heater core (A). 4.
